Zankap Weather Resistant CAT6 Inline Coupler RJ45 To RJ45 Joiner, Ideal For Installation Inside Conduit Or External Use

• Voltage rating: 125VAC RMS
• Current rating: 1.5Amp
• Contact resistance: 100 milliohms Max
• Insulation resistance: 1000 Megohms Min @500VDC
• Dielectric strength: 750 VAC RMS 60Hz, 1 Min
• Storage: -40°C to 85°C
• Operation: 0°C to 70°C
• Housing material: Nylon (PA66)
• Insert material: Flame Retardancy PBT
• PCB material: FR-4 T=1.6mm
• RJ45 jack contact: Phosphor bronze with nickel plating gold plated 50U
• RJ45 jack life: 750 times minimum
• Waterproof grade: IP68
• Cable OD: 5-7.5mm

Cable Test Results
