| Compatible hub models
Hub 2 (2G)
Hub 2 (4G)
Hub 2 PlusHub Hybrid (2G) Hub Hybrid (4G) |
| Compatible range extenders |
| ReX 2 |
| Jeweller communication technology |
| Proprietary wireless communication technology to transmit alarms and events
It features: |
| Two-way communication |
| Advanced anti-sabotage |
| Block encryption featuring a dynamic key |
| Instant notifications. |
| Remote configuration via the Ajax apps |
| Learn more |
| Frequency bands
866.0 – 866.5 MHz
868.0 – 868.6 MHz
868.7 – 869.2 MHz
905.0 – 926.5 MHz
915.85 – 926.5 MHz
921.0 – 922.0 MHz
Depends on the region of sales |
| Maximum effective radiated power (ERP)Up to 20 mW |
| Radio signal modulationGFSK |
| Radio signal rangeup to 1,700 m
Between detector and hub or range extender in an open space |
| Calculate radio signal range at the facility |
| Encrypted communication
All the data stored and transmitted are protected by block encryption with a dynamic key |
| Radio frequency hoppingRadio communication uses frequency hopping to prevent interception and jamming |
| Learn more |
| Wings communication technology |
| Proprietary wireless communication technology to transmit photo verifications.It features: |
| Two-way communication. |
| Block encryption featuring a dynamic key. |
| Advanced anti-sabotage. |
| Data package reloading in case of transmission errors. |
| Photo delivery check. |
| Learn more |
| Frequency bands
866.0 – 866.5 MHz
868.0 – 868.6 MHz
868.7 – 869.2 MHz
905.0 – 926.5 MHz
915.85 – 926.5 MHz
921.0 – 922.0 MHz
Depends on the region of sales |
| Radio signal rangeup to 1,700 mBetween detector and hub or range extender in an open space |
| Calculate radio signal range at the facility |
| Encrypted communicationAll the data stored and transmitted are protected by block encryption with a dynamic key. |
| Radio frequency hopping
Radio communication uses frequency hopping to prevent interception and jamming |
| Learn more |
| Sensitive element 1 × PIR sensor |
| Motion detection distanceup to 12 m
When installed at a height of 2.4 m. |
| Motion detection angleshorizontal — 88.5°vertical — 80° |
| Motion detection speedfrom 0.3 to 2.0 m/s
The direction of the detector lens should be perpendicular to an alleged intrusion path into the facility. |
| Sensitivity3 levels
Adjusted by PRO or user with admin rights in the Ajax app. |
| Pet immunityweight: up to 20 kgheight: up to 50 cmLearn more |
| False alarm preventionSmartDetectSoftware algorithm. |
| Temperature compensationEffective motion detection in temperatures from −10°C to +40°C. |
| Motion detection angles |
| Horizontal |
|
|
|  |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Vertical |
|
|
|
|
|
|
|  |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Photo by alarm
A built-in camera is activated if the detector is armed and motion is detected |
| |
| Photo on demand
User takes pictures at any time or when the detector is armed (depends on settings)
The feature is disabled by default |
| Learn more |
| Photo by scenario
A detector camera takes pictures automatically when Ajax fire detectors are triggered
The feature is disabled by default |
| Learn more |
| Photo resolution
640 × 480 px
320 × 240 px (by default)
160 × 120 px
Adjusted by PRO or user with admin rights in the Ajax app |
| IR backlight
For night photography and low light conditions. |
| Pictures in a seriesfrom 1 to 5 images with resolution of 320 × 240 px or 160 × 120 pxfrom 1 to 3 images with resolution of 640 × 480 px
Adjusted by PRO or user with admin rights in the Ajax app. |
| Photo delivery time
up to 7 s — 160 × 120 px resolution
up to 9 s — 320 × 240 px resolution
up to 20 s — 640 × 480 px resolution
When the hub is connected via Ethernet or 4G and the Wings signal strength between hub and device is 2–3 bars |
| Photo delivery time when the detector is connected via range extender is available here. |
| |
| It is recommended to install the detector at a height of 2.4 m |
| Device is designed for indoor use only |
| Tampering alarm
Alerts of attempts to detach the detector from the surface or remove it from the mounting panel |
| |
| Protection against forgery
device authentication |
| Communication loss detection within 36 s
Detection time depends on the Jeweller settings |
| Learn more |
| 2 × CR123A battery, 3 V
Up to 4 years of battery life |
| Dimensions
135 × 70 × 60 mm |
| Weight167 g |
| Operating temperature
range from −10°C to +40°C |
| Operating humidity
up to 75% |
| Protection class
IP50 |
|
|
|
 |
|
|
| MotionCam (PhOD)
Jeweller SmartBracket mounting panel Installation kit
2 × CR123A battery
Pre-installed
Quick Start Guide |
| Compliance with standards |
| |
| Warranty
24 months |
