| Part Number | Gap Inch (mm) | Loop Open/Closed | Reed Form | Max. Contact Rating (W) | Max. Initial Contact Resistance (mΩ) | Max. Switching Voltage (V) | Max. Switching Current (A) |
|---|---|---|---|---|---|---|---|
| TANE-86 Mini | 2.5″(64) | CLOSED | Normally Open | 10 | 100 | AC110/DC100 | 0.5 |
| * TANE-87 Mini Special Order | 2.05″(52) | OPEN | Normally Closed | 3 | 100 | AC30/DC30 | 0.2 |
| * TANE-88 Mini Special Order | 1.97″(50) | SPDT | SPDT | 3 | 100 | AC30/DC30 | 0.2 |
Operating Temperature:-40°C to +60°C
-
Tane MET-44WGTane Standard Roller Shutter Reed Switch
Contact Size: 4.22″L×1.73″W×.47″H (107.2mm×44mm×12mm) Standard Magnet Size: 4.13″L×2.42″W×1.5″H (105mm×61.7mm×38mm) Standard Gap: 2″(50mm) Colors: ...
View full details -
Sold out -
Zankap Pty Ltd 2202AU-LSentrol Standard Roller Shutter Reed Switch With 3" Gap And Universal Magnet
Sentrol Standard Roller Shutter Reed Switch With 3" Gap And Universal Magnet
-
Zankap Pty Ltd 2302A-LSentrol Channel Mount Roller Shutter Reed Switch
Sentrol Channel Mount Roller Shutter Reed Switch
