Low Current consumption - 175mA @12Vdc after 1 second
Mounting kit supplied as standard
Australian designed
High traffic areas
Fire rated door sets
Open in/open out doors
Suitable for use with all access control systems
S3 (Security) Australian Lock Standard (AS4145.2.· 2008)
D3 (Durability) Australian Lock Standard (AS4145.2· 2008)
BS 5872 Approved
Successfully fire rated up to 4hrs on fire door assemblies in accordance with AS1905.1 (Part 1: Fire resistant door sets)
For any fire rated applications of this product, the fire certification should be investigated and examined to ensure the suitability & configuration of this product for that particular door assembly. Contact the supplier for further details, such as certifications, door type and door thickness etc. that may affect the fire door suitability and rating.
Approved to UL1034 (highest level)
CE approved (EMC, ROHS & REACH)
Regulatory Compliance Mark (RCM) approved
Voltage 12 or 24Vdc
Current 175 mA @ 12Vdc - 88 mA @ 24Vdc
Solenoids Solenoids are rated for continuous use
Monitoring None
Holding Force 850kg Static Strength Rating
Endurance Cycle tested to 1,000,000 operations
Latch Suitable for 15mm latch bolt with 3mm door gap
Environment Operational temperature range -20°C to +60°C
Body Solid Stainless Steel Construction
Keeper Stainless Steel
Specification Statement The strike should be constructed of stainless steel, have a minimum holding force of 850kg and have an endurance rating of 1 million cycles. The one strike must be changeable from fail safe to fail secure on site where required. The strike should not consume current greater than 175mA at 12Vdc and have a solenoid rated for continuous use.
