Decoding

Description

Decoding Format

Ultra 265,H.265,H.264

Decoding Capability

NVR301‑04B‑IQ:Smart Off：2 x 12MP@30, 2 x 4K@30, 4 x 4MP@30

Smart On：2 x 4K@30, 4 x 4MP@30

NVR301‑08B‑IQ:Smart Off：2 x 12MP@30, 2 x 4K@30, 4 x 4MP@30, 8 x 1080P@30

Smart On：2 x 4K@30, 4 x 4MP@30, 8 x 1080P@30

NVR301‑16B‑IQ:Smart Off：2 x 12MP@30, 2 x 4K@30, 4 x 4MP@30, 10 x 1080P@30, 16 x 720P@30

Smart On：2 x 4K@30, 4 x 4MP@30, 8 x 1080P@30, 16 x 720P@30

Audio Compression

G.711A, G.711U

Network

Description

Incoming Bandwidth

80Mbps

Outgoing Bandwidth

80Mbps

Remote Users

128

Protocols

TCP/IP; P2P; NTP; DHCP; PPPoE; HTTP; HTTPS; DNS; DDNS; SNMP; SMTP; RTSP; IPv6; IPv4

Browser(Plugin)

Windows:IE(IE10/11),Firefox (version 52.0 and above),Chrome(version 45 and above),Edge(version 79 and above)

Video/Audio Input

Description

IP Video Input

NVR301‑04B‑IQ:4‑ch

NVR301‑08B‑IQ:8‑ch

NVR301‑16B‑IQ:16‑ch

RCA Audio Input

1‑ch

Video/Audio Output

Description

HDMI Output

4K(3840x2160)/30Hz, 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz

VGA Output

1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz

RCA Audio Output

1‑ch

Liveview Display

NVR301‑04B‑IQ:1/4/6/8/9

NVR301‑08B‑IQ/NVR301‑16B‑IQ:1/4/6/8/9/16

Corridor Mode Screen

NVR301‑04B‑IQ:3/4

NVR301‑08B‑IQ:3/4/5/7/9/10

NVR301‑16B‑IQ:3/4/5/7/9/10/12/16

Two-way Audio

Description

Two-way Audio

1‑ch,RCA(Using the audio input and output)

Snapshot

Description

FTP/Schedule/Event Snapshot

4‑ch snapshot,up to D1 resolution

Recording

Description

Recording Resolution

12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P/D1/2CIF/CIF

Num of Concurrent Playback

16‑ch

Smart

Description

VCA Detection by IPC

Face Detection; face detection; Vehicle Detection; SIP(Intrusion Detection,Cross Line Detection,Enter Area,Leave Area); Ultra Motion Detection (UMD); People Counting(People Flow Counting,Crowd Density Monitoring); Traffic Monitoring

Smart by NVR

face detection; Smart Intrusion Prevention (SIP); Ultra Motion Detection(UMD)

VCA Search

Motor Vehicle Search; Non‑Motor Vehicle Search; Human Body Search; General Search; People Counting Report; Heat Map

Smart by IPC

All channels (up to 8 images/s in total)Face Detection,face detection,Vehicle Detection,SIP,UMD,Traffic Monitoring

Search by Image

Support

SIP by NVR

2‑ch

UMD by NVR

4‑ch

Alarm

Description

General Alarm

Defocus Detection; Scene Change Detection; Object Left Behind; Object Removed; Auto Tracking; Motion Detection; Tampering; Human Body Detection; Video Loss; Alarm Input; Audio Detection

Alert Alarm

IP Conflict; Network Disconnected; Disk Offline; Disk Abnormal; Illegal Access; Hard Disk Space Low; Hard Disk Full; Recording/Snapshot Abnormal

GUI Language

Description

GUI Language

38 languages: Simplified Chinese, Traditional Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian, Estonian, Bulgarian, Greek, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenia, Serbia, Korean, Japanese, Latvian, Lithuanian, Persian

Hard Disk

Description

SATA

1 SATA Interfaces

Capacity

Up to 10TB for each HDD (The maximum HDD capacity varies with environment temperature)

External Interface

Description

Network Interface

1 RJ45 10M/100M self‑adaptive Ethernet Interface

USB

Rear panel: 1 x USB2.0, 1 x USB3.0

RS485

N/A

RS232

N/A

Alarm In

N/A

Alarm Out

N/A

Power Supply

DC 12V/2A

Power Switch

Support

Working Environment

Description

Working Temperature

‑10°C ~ + 55°C (+14°F ~ +131°F)

Working Humidity

≤ 90% RH (non‑condensing)

Power Consumption (without HDD)

≤ 12W

Dimensions

Description

Weight (without HDD)

≤ 2Kg (4.4lb)

Height

1U

Dimensions

260mm × 222mm × 47mm (10.2"×8.7"×1.8")

Certification

Description

Certification

CE, FCC, UL, RoHS, WEEE

FCC

Part15 Subpart B
