| Module Connection (RS485 LAN) | Max. total LAN length using multi strand security cable = 300m Max. total LAN length using 2 pair twisted shielded data cable (Belden 8723) = 1200m. See installation manual for complete wiring instructions. |
| Communications | CID, SIA, E-mail, Voice, GMS-SMS, Connetix IP, CSV-IP |
| Connectivity | Proprietary RS485 LAN. Vision-X, Vision-XIP, Solution 6000 and Solution 6000-IP Panels supported |
| Battery capacity (Ah) | 7.2 Ah |
| Input voltage (VAC) | 16 VAC – 18 VAC |
| Operating voltage (VDC) | 10.2 VDC |
| Type of power supply | VAC; Battery |
| Battery Type | Bosch BA 12V 7.2AH or equivalent. (Secondary Power Source). |
| Battery Charger | Pulse by pulse charger. (Note: Charge voltage cannot be measured unless battery is fitted.) |
| Continuous Power | 1 Amp MAX (combined power drawn from Accessory Power (+12V) LAN Power (Module LAN +) and Output Power (C+) terminals must not exceed 1 Amp. |
| Power | +12VDC, 110mA Max (LAN powered +9VDC - +16VDC) |
| Operating temperature (°C) | 0 °C – 55 °C |
| Operating relative humidity, non-condensing (%) | 5% – 85% |
| Color | White |
| Dimensions (H x W x D) (mm) | 149 mm x 88 mm x 21.5 mm |
| Wi-Fi standard | IEEE 802.11n; IEEE 802.11g; IEEE 802.11b |
| Display color | Color |
