| Material | High impact ABS plastic enclosure |
| Dimensions | 3.05 cm x 11.7 cm (1.2 in. x 4.6 in.) |
| Temperature (operating) | -29Β°C to +49Β°C (-20Β°F to +120Β°F) For UL Certificated installations, 0Β°C to +49Β°C (+32Β°F to +120Β°F) |
| Radio Frequency Interference (RFI) Immunity | No alarm or setup on critical frequencies in the range from 26 MHz to 950 MHz at 50 V/m. |
| Height range | 2 m to 3.6 m (7 ft to 12 ft) |
| Location | Surface or semi-flush on ceiling or on standard 10 cm (4 in.) octagonal electrical box |
| Pattern pointability | Β±15Β° rotational |
| Alarm | Normally-closed reed relay rated at 3.0 W, 125 mA at 28 VDC for resistive loads and protected by a 4.7 Ξ© resistor in the common C leg. |
| Tamper | Normally-closed cover activated tamper switch with separate terminals. Tamper contacts rated 125 mA at 28 VDC maximum. |
| Current | 20 mA at 12 VDC |
| Voltage | 10 VDC to 15 VDC |
