System |
Main Processor | Embedded processor |
Operating System | Android 8.1 |
Network Protocol | IPv4, TCP, SIP, UDP, RTSP |
Basic |
Screen Type | Capacitive screen |
Display Screen | 10 inch TFT LCD |
Resolution | 1024×600 |
Video Compression | H.264 |
Audio Compression | PCM |
Audio Input | 1 omnidirectional microphone |
Audio Output | Built-in 1.5W speaker |
Audio Mode | Two-way voice call |
Audio Enhancement | Echo suppression/DNR |
Audio Bit Rate | 16KHz, 16Bit |
Function |
Information Release | Text announcements released by the management center can be viewed |
Communication Mode | Full digital |
Elevator Control | You can control the elevator through the indoor monitor |
Leave Videos or Text Messages | Yes (SD card is needed) |
DND Mode | Do not disturb period can be set. |
Extension Number | Villa: 4 Apartment: 9 |
Wi-Fi | Yes |
Wireless Standard | IEEE802.11b/802.11g/802.11n |
Wireless Frequency Range | 2.4GHz |
Wireless Security-Encryption | 64/128bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
Storage | Micro SD storage, the maximum space is 256GB |
Port |
RS-485 | 1 |
Alarm Input | 8 |
Alarm Output | 1 |
Power Output | 1 12V/100mA |
Door Bell | Yes, use alarm input port |
Network Port | 1 10M/100M Ethernet |
Alarm |
SOS | Yes |
Performance |
Housing Material | PC+ABS |
Regular |
Color | Black |
Power Supply | 12V DC 1A
Standard POE |
Installation | Surface mount |
Certifications | CE
FCC |
Accessory | Surface mount bracket, alarm ribbon cable, RS-485 cable, and power-supply pins are provided |
Product Dimensions | 260 mm×170 mm×15 mm (10.24"×6.69"×0.59") (ports are not counted) 260 mm×170 mm×25.4 mm (convex) (10.24"×6.69"×1") (ports are counted) |
Operating Temperature | -10°C to +55°C (+14°F to +131°F) |
Operating Humidity | 10%RH–95%RH (Non-condensing) |
Operating Altitude | Less than 3,000 meters (9842.52 ft) |
Power Consumption | ≤1.5W (standby), ≤7W (working) |
Net Weight | 770g (1.70lb) |
Gross Weight | 1.1kg (2.43lb) |
