Bticino* IP 10" Touchscreen External Station With Card Reader. Includes Flush Mount Box. IP54, IK07

by Bticino
SKU 374002

Notify me when back in stock

Video entrance panel with 10” touch display and badge reader for access control functions.

  • The entrance panel can be PoE (power over Ethernet) powered, or directly powered using power supply BT-375005.
  • Flush mounted installation using the dedicated box BT-375007
  • Configuration of different calling modes:

           - Apartment code (Area - Building - Riser - Floor - Apartment)

           - Numeric or alphanumeric codes for residents

           - Address book with contact list.

  • Possibility to upload customized screensavers and advertisements using the configuration software.



Brand
BTicino
Rated voltage
24Vdc
Protection index
IP54
Dimensions
430 x 195 x 58mm
Height
430mm
Width
195mm
Depth
58mm
Max section
0,8mm2
Plant type
IP
Connection
RJ45
Degree of robustness
IK07
Recommended installation height
160 - 165cm
Operating temperature
(-40°) - (+70°)C
Resolution
1080p
Facial recognition distance
30 - 80cm
Color
Silver
Series EN
IP Door Entry System
