System Parameter | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Host Processor | Embeded processor | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Camera | 1/2.8" 2MP CMOS high definition low illumination colorful | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Angle of view | D:180° H:160° V:82° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focal length | 1.95 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
WDR | Support | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Noise reduction | Noise suppression and echo cancellation | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video encoding | H.264 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Frame rate | PAL:25 fps NTSC:30 fps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio encoding | G.711 U | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video bit rate | 256K to 2M | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Light compensation | IR Supplement | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Port | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RS-485 Port | 1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Output | 1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lock Control | 1 set | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Door Status Detection | 1 set | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Eoc | 1 set | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Exit Button | 1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Tamper Switch | 1 set | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Interface | 1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Output | 12V/100mA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Parameter | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Tamper Alarm | Support | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Door Sensor Timeout Alarm | Support | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Iutput | Support | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Output | Support | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
User Parameter | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Input | Built-in Omnidirectional Microphone | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Output | Built-in Loudspeaker | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Status Indicator | calling&communication&unlocked | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Communication Methods | Digital communication | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Unlock Mode | Remote unlocking | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Auto Snapshot | Support | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Leave Videos or Text Messages | Support | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage |
