Channel 1: 1/1.2" Progressive Scan CMOS,
Channel 2: 1/1.8 Progressive Scan CMOS"
Channel 1: Color: 0.0003 Lux @ (F1.2, AGC ON), 0 Lux with Light, B/W: 0.0001 Lux @ (F1.2, AGC ON), 0 Lux with IR,
Channel 2: Color: 0.0003 Lux @ (F1.0, AGC ON), 0 Lux with Light, B/W: 0.0001 Lux @ (F1.0, AGC ON), 0 Lux with IR
IR cut filter,
Blue glass module (less ghost phenomenon)
Channel 1: 10 to 50 mm: horizontal FOV 36° to 13.1°, vertical FOV: 20.4° to 7.4°, diagonal FOV 41.8° to 14.9°
Channel 2: 4 mm: horizontal FOV: 89°, vertical FOV: 45°, diagonal FOV: 107°
Channel 1: P-iris,
Channel 2: Fixed
Channel 1: Constant F1.6 throughout the zoom range,
Channel 2: F1.0
Channel 1:
Wide: D:241.4 m, O: 95.8 m, R: 48.3 m, I: 24.1 m
Tele: D: 620.7 m, O: 246.3 m, R:124.1 m, I: 62.1 m
Channel 2:
D:77 m, O: 30.5 m, R: 15.4 m, I: 7.7 m
Channel 1: up to 120 m,
Channel 2: up to 30 m
Channel 1:
50 Hz: 25 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 24 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)
Channel 2:
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Channel 1:
50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 24 fps (704 × 480, 640 × 480)
Channel 2:
50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480)
Channel 1:
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60 Hz: 24 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Channel 2:
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Channel 1:
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60 Hz: 24 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Channel 2:
50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480)
Channel 1:
50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 24 fps (704 × 480, 640 × 480)
Channel 2:
50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480)
Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264,
Fourth stream: H.265/H.264/MJPEG,
Fifth stream: H.265/H.264/MJPEG
Up to 32 users
3 user levels: administrator, operator, and user
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),
Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Plug-in required live view: IE 10, IE11,
Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Channel 1: Day, Night, Auto, Schedule, Alarm Trigger, Video Trigger,
Channel 2: Day, Night, Auto, Schedule, Alarm Trigger
Channel 1: BLC, HLC, 3D DNR, Defog, EIS,
Channel 2: BLC, HLC, 3D DNR, Defog
1 input (line in), 3.5 mm connector, three-contact, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,
1 output (line out), 3.5 mm connector, three-contact, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium, mono sound
Channel 1,
Detects up to 60 targets simultaneously,
Supports simultaneous detection and capture of human body, face and vehicle,
Gets 7 face features,
Gets 13 human body features,
Gets 2 vehicle features
Channel 1,
Detects up to 120 faces simultaneously,
Supports swing left and right from -60° to 60°, tilt up and down from -30° to 30°,
Uploads face with background and closed-up face pictures
Channel 1,
Up to 10 face libraries. 30,000 faces for each library. 150,000 faces in total. ,
Recognizes face identity via face modeling, grading and comparing to those in face library,
Supports face library encryption
Channel 1,
Line crossing, intrusion, region entrance, region exiting,
Support alarm triggering by specified target types (human and vehicle),
Channel 2,
Line crossing, intrusion, region entrance, region exiting,
Support alarm triggering by specified target types (human and vehicle)
Channel 1,
Blocklist and allowlist: up to 10,000 records
Support license plate recognition of motorcycles (only in checkpoint scenario)
Support vehicle attribute detection, including vehicle type, color, brand, etc. (City Street mode is recommended.)
License plate recognition rate ≥98%
Three-core terminal block,
12 VDC ± 20%, 1.90 A, max. 22.7 W,
24 VAC ± 20%, 1.39 A, max. 22.3 W,
PoE: IEEE 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.59 A to 0.44 A, max. 24.7 W
With -H: -40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing),
Without -H: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
FCC: 47 CFR Part 15, Subpart B,
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7,
KC: KN32: 2015, KN35: 2015
UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
LOA: IEC/EN 60950-1
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
