Ruijie Reyee External Wireless Bridge Kit, 100Mbps, 2.4GHz, 2 x 24VDC POE Injectors / 12VDC Input, IP55 (Up To 500M Range)

Ruijie Reyee External Wireless Bridge Kit, 100Mbps, 2.4GHz, 2 x 24VDC POE Injectors / 12VDC Input, IP55 (Up To 500M Range)

by Ruijie Reyee
Please login to view price
SKU RG-EST100-E
Please login to Add to Cart

Notify me when back in stock

Reyee by Ruijie RG-EST100-E, 2.4GHz Dual-stream Up To 500m Wireless Bridge

  • Support maximum 10 @ 3MP cameras loading at 100m, Or 5 @ 3MP cameras loading at 500m
  • Factory-free configuration, without complex alignment
  • IP55 Weatherproof, -30℃~60℃ guarantee stable operating at outdoor or elevator environment
  • Visually Intuitive statistics monitoring on Ruijie cloud, easy maintenance at remotely
Radio Design
2.4 GHz Single-Band Dual-Stream
Transmission Protocol
IEEE 802.11b/g/n
Operating Band
802.11b/g/n: 2.400～2.483GHz
Antenna
Directional antennas, 8 dBi
Polarization
Horizontal: 70°, Vertical: 70°
Bridging Distance
500m (recommended)
Spatial Streams
2x2, MU-MIMO
Memory/Flash
64 MB/8 MB
Maximum Throughput
Up to 300 Mbps at 2.4 GHz
Max. Transmit Power
≤100 mW(20 dBm) (adjustable)
IP Rating
IP55
Lightning Protection
±6 KV(Common Mode)
Installation
Wall-mounted/ Pole-mounted
Dimensions （D x W x H）
165.5mm×68.7mm×42mm
Weight
0.3 kg

Datasheet

Installer Reference Guide
