Extreme protection for Home & Commercial High value properties.
The High Security Field is created by balancing the external and internal magnetic fields.
Attempting to bring an external magnet to defeat the security switch triggers the alarm.
| Part Number | Gap Inch (mm) | Loop Open/Closed | Reed Form | Max. Contact Rating (W) | Max. Initial Contact Resistance (mΩ) | Max. Switching Voltage (V) | Max. Switching Current (A) |
|---|---|---|---|---|---|---|---|
| FM-102 HS | .39″~.79″ (10~20) | CLOSED | Normally Open | 3 | 100 | 30 | 0.2 |
| FM-106 HS | .39″~.98″ (10~25) | CLOSED | Normally Open | 3 | 100 | 30 | 0.2 |
| TANE-55 HS | .47″~.94″ (12~24) | CLOSED | Normally Open | 3 | 100 | 30 | 0.2 |
| SM-35 HS | .39″~.98″ (10~25) | CLOSED | Normally Open | 3 | 100 | 30 | 0.2 |
| TANE-60 QC HS | .2″~.59″ (5~15) | CLOSED | Normally Open | 3 | 100 | 30 | 0.2 |
| TANE-50 HS | .31″~.79″ (8~20) | CLOSED | Normally Open | 3 | 100 | 30 | 0.2 |
| GP-23 HS | .39″~.94″ (10~24) | CLOSED | Normally Open | 3 | 100 | 30 | 0.2 |
| SS-40 HS | .59″~1.1″ (15~28) | CLOSED | Normally Open | 3 | 100 | 30 | 0.2 |
| MET-200 HS | .59″~1.38″ (15~35) | CLOSED | Normally Open | 3 | 100 | 30 | 0.2 |
| MET-200AR HS | .59″~1.38″ (15~35) | CLOSED | Normally Open | 3 | 100 | 30 | 0.2 |
| SM-20 HS | .59″~1.77″ (15~45) | CLOSED | Normally Open | 3 | 100 | 30 | 0.2 |
| TANE-66WG HS | .39″~1.97″ (10~50) | CLOSED | Normally Open | 3 | 100 | 30 | 0.2 |
| TANE-96BI HS | .39″~2.17″ (10~55) | CLOSED | Normally Open | 3 | 100 | 30 | 0.2 |
| TANE-96BI LG HS | .39″~2.17″ (10~55) | CLOSED | Normally Open | 3 | 100 | 30 | 0.2 |
-
Tane MET-44WGTane Standard Roller Shutter Reed Switch
Contact Size: 4.22″L×1.73″W×.47″H (107.2mm×44mm×12mm) Standard Magnet Size: 4.13″L×2.42″W×1.5″H (105mm×61.7mm×38mm) Standard Gap: 2″(50mm) Colors: ...
View full details -
Tane TANE-86Tane Mini Roller Shutter Reed Switch
Contact Size: 2.13″L×1.37″W×.37″H(54mm×34.7mm×9.5mm) Standard Magnet Size: 2.64″L×2.13″W×1.13″H(67mm×54mm×28.7mm) Standard Gap: 2.5″(64mm) Colors: ...
View full details -
Sentrol 2202AU-LSentrol Standard Roller Shutter Reed Switch With 3" Gap And Universal Magnet
The Interlogix 2202 Series overhead door magnetic contact is for use in the rigorous environments of commercial and industrial installations.
-
Sentrol 2302A-LSentrol Channel Mount Roller Shutter Reed Switch
Overhead door contact for curtain style overhead doors with 60cm steel armoured cable, N/C contact, gap 7.6cm
