System |
Main Processor | Embedded processor |
Operating System | Embedded Linux operating system |
Network Protocol | IPv4; FTP; UPnP; SNMP; DNS; DDNS; RTSP; RTP; TCP; UDP; SIP |
Basic |
Screen Type | Capacitive touchscreen |
Display | 7" TFT |
Screen Resolution | 1024 × 600 |
Audio Compression | G.711a; G.711u; PCM |
Audio Input | 1 |
Audio Output | Built-in speaker |
Audio Mode | 2-channel |
Audio Enhancement | Echo suppression |
Audio Bit Rate | 16 kHz; 16 bit |
Function |
Communication Mode | Full digital |
Information Release | Receive and view text information released by the management center |
DND Mode | Do not disturb period can be set; Do not disturb mode |
Number of Extensions | Villa: 9
Apartment: 4 |
Performance |
Casing | PC + ABS |
Port |
Alarm Input | 6 |
Alarm Output | 1 |
Power Output | 1 (12 V/200 mA) |
Door Bell | Yes (use any alarm input port) |
Network | One 10/100 Mbps Ethernet |
Alarm |
SOS | Yes |
General |
Color | White |
Power Supply | 12 VDC 1A;
Standard PoE (36–57 V, 0.35 A) |
Installation | Surface Mount |
Certifications | CE; FCC |
Accessory | Bracket and alarm ribbon cable (included) |
Dimensions | 189.6 mm × 134.6 mm × 26.0 mm (7.50" × 5.30" × 1.00") |
Operating Temperature | –10 °C to +55 °C (+14 °F to 131 °F) |
Operating Humidity | 10%–95% RH (non-condensing) |
Operating Altitude | Beneath 3,000 m (9,842.52 ft) |
Power Consumption | Standby ≤ 2 W; working ≤ 6 W |
Net Weight | 0.34 kg (0.74 lb) |
Gross Weight | 0.58 kg (1.27 lb) |
