Radio communication protocol | Jeweller |
Learn more | |
Radio frequency band | 866.0 – 866.5 MHz |
868.0 – 868.6 MHz | |
868.7 – 869.2 MHz | |
905.0 – 926.5 MHz | |
915.85 – 926.5 MHz | |
921.0 – 922.0 MHz | |
Depends on the region of sale. | |
Compatibility | Operates with all Ajax hubs, radio signal range extenders, ocBridge Plus, uartBridge |
Maximum RF output power | Up to 20 mW |
Modulation of the radio signal | GFSK |
Radio signal range | Up to 1,300 m (any obstacles absent) |
Learn more | |
Power supply | 2 × AAA batteries |
Power supply voltage | 3 V (batteries are installed in pairs) |
Battery life | Up to 5 years |
Dust and moisture protection class | IP65 |
Installation method | Indoors |
Operating temperature range | From 0°С to +50°С |
Operating humidity | Up to 100% |
Overall dimensions | 56 × 56 × 14 mm |
Weight | 40 g |
Service life | 10 years |
