- Voltage: 11.4 - 26VDC
- Current: Peak Current: 1000mA, Idle Current: 35mA @12VDC with LED activated
- Unlocking Pre-Load: Side Load rated: Motorised unlocking - 100kg max at the bolt
- Strength: Maximum 1000kg
- Monitoring: Lock Status Monitoring: NO/NC, Door Position Monitoring: NC
- Unlocking Time: 1 Second under Preload
- Locking Time: 3 Seconds
- Environment: Weather resistant construction to IP53
- Operating Temperature: -10 to +60 Degrees Celsius
- Endurance: 500,000 operations (120N Unlocking, 50N Locking)
- Dimensions: Body: 210L x 24W x 42D (mm), Faceplate: 256L x 30W (mm), Strike Plate: 256L x 30W (mm)
- Construction: Stainless Steel lock body, Face plate and Strike Plate
Specification Statement:
The lock must be a high torque motorised bolt with pre-load tolerance, capable of unlocking with up to 100kg of side pressure (Pre-Load) and Locking up to 35kg Pre-Load. The lock must have a minimum IP Rating of IP53, include integrated lock status and diagnostics LED indication, lock status and door position monitoring and be site configurable for Fail Safe (PTL) or Fail Secure (PTO) operation. The lock shall accept an operating voltage between 11.4 to 26VDC and draw no more than 1000mA during change of state and 35mA when idle.
The strike plate must be shaped in a V format to accommodate up to 12mm (total) for misaligned doors. The lock must be triggered with a magnet positioned in the strike plate and be monitored for locked, unlocked and door position.
Dimensions
Standards and Compliance
- S8 (Security) Australian Lock Standard (AS4145.2.2008)
- D8 (Durability) Australian Lock Standard (AS4145.2.2008)
- IP53 Rating
