| Sensor | PIR sensor, 2 pcs |
| Detection angles | Horizontal — 6°; vertical — 90° |
| Time for motion detection | From 0.3 to 2 m/s |
| Placement | Indoor only |
| Motion detection range | Up to 15/13/11 m (up to 8/7/6 m with Correlation Signal Processing enabled depending on sensitivity settings) |
| False alarm reduction | Available — Correlation Signal Processing |
| Tamper Protection | Available — detector body detachment and damage |
| Radio communication protocol | Jeweller |
| Learn more | |
| Radio frequency band | 866.0 – 866.5 MHz |
| 868.0 – 868.6 MHz | |
| 868.7 – 869.2 MHz | |
| 905.0 – 926.5 MHz | |
| 915.85 – 926.5 MHz | |
| 921.0 – 922.0 MHz | |
| Depends on the region of sale. | |
| Compatibility | Operates only with all Ajax hubs, and radio signal range extenders |
| RF signal strength | Up to 20 mW |
| Radio signal modulation | GFSK |
| Radio signal range | Up to 1700 m line-of-sight |
| Power supply | 1 battery CR123A, 3 V |
| Battery life | Up to 3 years |
| Installation method | Indoors only |
| Operating temperature range | From -10°С to +40°С |
| Protection class | IP54 |
| Overall dimensions | 134 × 44 × 34 mm |
| Weight | 118 g |
| Service life | 10 years |
